1.Product Introduction of Flexible transparent film screen
Bending Reality: Explore the Wonders of LED Crystal Film Screen
Step into a world where innovation defies limits and imagination takes center stage. Introducing the LED Crystal Film Screen – a technological marvel that reshapes what you thought was possible. With its remarkable ability to effortlessly bend and curve, this display opens the door to a realm of endless possibilities, transforming spaces, and captivating minds.
Unleash Your Creativity: LED Crystal Film Screen
Experience the freedom to shape your surroundings like never before. The LED Crystal Film Screen's exceptional feature of seamless bending and curving empowers you to design immersive environments that transcend boundaries. From curvaceous installations to dynamic displays, your creativity knows no bounds.
Unveil Breathtaking Realms: LED Crystal Film Screen
Witness visuals come to life in ways you've never imagined. The LED Crystal Film Screen's unique flexibility allows it to adapt effortlessly to any surface, creating a visual spectacle that wraps around your senses. Immerse yourself in a breathtaking world where reality bends to your will.
A New Era of Entertainment: LED Crystal Film Screen
Elevate your entertainment experience to a whole new level. The LED Crystal Film Screen's ability to bend and curve means you can transform any space into a captivating theater of sights and sounds. Whether it's for gaming, movies, or presentations, get ready to be immersed in a dynamic world that bends to your desires.
Innovate Your Space: LED Crystal Film Screen
Turn your environment into a canvas of innovation. The LED Crystal Film Screen's flexibility allows you to seamlessly integrate it into architectural designs, retail displays, or even artistic installations. Break free from traditional displays and let your space become a masterpiece of bending brilliance.
2.Product Parameter (Specification) of Flexible transparent film screen
Product Model |
P4 |
P4-8 |
P6 |
P8 |
P10 |
P16 |
P16-32 |
P32 |
P20-60 |
Pixel Pitch |
4*4mm |
4*8mm |
6*6mm |
8*8mm |
10*10mm |
16*16mm |
16*32mm |
32*32mm |
20*60mm |
Pixel |
62500 Dots/m2 |
31250 Dots/m2 |
2 755 6 Dots/m2 |
15625 Dots/m2 |
10000 Dots/m2 |
3844 Dots/m2 |
1922 Dots/m2 |
961 Dots/m2 |
800 Dots/m2 |
LED Specification |
SMD1010(Light Drive) |
SMD2121(Light Drive) |
|||||||
Pixel Composition |
1R1G1B |
1R1G1B |
1R1G1B |
1R1G1B |
1R1G1B |
1R1G1B |
1R1G1B |
1R1G1B |
1R1G1B |
Module Size |
800mm*240mm |
1000mm*240mm |
1000mm*240mm |
1000mm*240mm |
1000mm*240mm |
1000mm*240mm |
1000mm*240mm |
1000mm*240mm |
1000mm*240mm |
Module Resolution |
200*60 |
250*30 |
166*40 |
125*30 |
100*24 |
62*15 |
62*7 |
31*7 |
50*4 |
Pixel Resolution |
250*250/m2 |
250*125/m2 |
166*1 66/m2 |
125*125/m2 |
100*100/m2 |
62*62/m2 |
62*31/m2 |
31*31/m2 |
50*16/m2 |
Permeability |
≧85% |
≧85% |
≧85% |
≧85% |
≧90% |
≧90% |
≧95% |
≧95% |
≧95% |
Box Wiring Mode |
Internal Wiring(Tidy Back) |
||||||||
Weight |
≦3. 5KG/m2 |
≦3. 5KC/m2 |
≦3. 5KC/m2 |
≦3. 5KG/m2 |
≦3. 5KG/m2 |
≦3. 5KG/m2 |
≦3. 5KG/m2 |
≦3. 5KG/m2 |
≦3.5KG/m2 |
White Balance Brightness |
≧3000cd/m2 |
≧3000cd/m2 |
≧3000cd/m2 |
≧3500cd/m2 |
≧3500cd/m2 |
≧3500cd/m2 |
≧2500cd/m2 |
≧1500cd/m2* |
≧600~800cd/m2 |
Peak Power Consumption |
600 W/m2 |
||||||||
Average Power Consumption |
About 200 W/m2 (According To The Video ) |
||||||||
Frame Change Frequency |
≧8000Hz |
||||||||
Grayscale Level |
16Bit |
||||||||
Brightness Control Level |
0-255 |
||||||||
CCT |
3200K-8500K (Adjustable) |
||||||||
Refresh rate |
360Hz |
||||||||
Viewing Angle |
H-H140 Degree V-V140 Degree |
||||||||
Input Signal |
DVI/VGA、Composite Video |
||||||||
Screen Contol Type |
Or synchronous box (computer control screen) or asynchronous box (WiFi connection mobile phone APP control screen, U disk control screen) |
||||||||
Protection Grade |
IP3O |
||||||||
Power Requirements |
AC 220V ± 10%, 50-60Hz, (optional wide voltage 110V and 9-36V) |
||||||||
Working Temperature |
-20〜50 Degree |
||||||||
Theoretical Service Life Time |
100000 Hours |
3. Product Feature And Application of Flexible transparent film screen
1). Flexible transparent film screen, LED crystal film screen has high light transmittance, and the base material is high temperature resistant PET film. When the screen stops working, it can be fully integrated into the glass
2). Ultra-thin and Ultra-light LED transparent flexible film screen, the thickness is only 3-5mm, and the weight is as light as 4.5kg/㎡
3). Flexible transparent film screen :Bendable, the LED crystal film screen is flexible and can be attached to curved glass buildings
4). Customization :It can be cut, supports arbitrary cutting, is not limited by size and shape, meets the needs of different sizes, and realizes more creative display
5). Wide viewing angle, each angle is 140°, no dead angle, no color cast, every side is wonderful
6). Energy saving and environmental protection transparent film screen,Safe and beautiful, no components in the screen body, hidden power supply, safe and reliable,The average power consumption per square meter of the transparent crystal film display is very low compared with conventional displays, energy saving and environmental protection
7). Quick installation, simple and fast, can be directly pasted on the glass surface
8). Flexible transparent film screen, The transparent crystal film screen achieves high-definition display effect on the basis of transparency
9).High-end transparent film screen, In some places, the use of transparent crystal film screens can not only achieve publicity display, but also improve the grade of the place, which is refreshing and enhances the sense of technological atmosphere.
4. Application of Flexible transparent film screen
1). Advertising for Glass Curtain Wall Building
2). Glass window decoration
3). Sightseeing elevator advertisement
4). Internal space of commercial complex
5). Glass guardrail
6). Transparent display can be applied to both glass and transparent areas
5. Product Details of Flexible transparent film screen
|
Others |
Ours |
Advantage |
Control Method |
Lamp bead withstand voltage |
5V |
3.8V-12V |
When the current is unstable, the lamp bead is stable |
Be Indicated in The Bid Proposal A 12v power supply test machine to support you to test the voltage |
gray scale |
8BIT to 16BIT |
16BIT |
With Greater Video Display Effective |
Test high grayscale photos and videos While Installation |
Line Width |
Visible Line Width 150μm |
Invisible Line Width 30μm |
Excellent light transmittance |
Field comparison |
Lamp Beads Size |
1515/2121 |
1010/2121 |
Small lamp bead with high light transmittance |
Lamp bead size 1010 |
Connector |
Conventional connector |
Imported FCI high density connector |
High stability Multiple plugging and unplugging without failure |
testing on the spot |
LED thrust |
Under 1.5KG or Less |
Over 3KG |
The pad is firm high stability |
Sample Provided For Test On-Site Random Sampling Test On-Site on Inspection |
Line adhesion |
Failed to pass the 100-gram test |
pass the 100 grid test |
Installation Transport Maintenance The line is not easy to damage |
data detection |
6. Product Qualification of Flexible transparent film screen
7. Deliver,Shipping And Serving of Flexible transparent film screen
